Used Label Converting Equipment
Clients often ask us if we can offer used Label Finishing and Printing Presses. Daco sometimes has equipment that has been part-exchanged against equipment from our range of Inspection / Slitter Rewinders, Rotary Die Cutters and Turret Rewinding Equipment.
If you have equipment now or in the future, please complete our online Selling Equipment form, and we will pass the equipment details to any potential clients. We have a small range of finishing equipment that has been part exchanged or asked to market by clients using Daco equipment.
Daco SR350 Label Slitter Rewinder
Unwind
- Maximum unwind diameter: 700mm (27.5″)
- 76mm (3″) diameter air shaft
- Merobel electromagnetic particle brake
- Automatic taper tension control
- End of roll function – The user can program the roll end diameter – slowdown and/or stop – The system does not use any roll followers or external sensors that can be damaged at roll changes. The diameter is programmed from the touch screen operator interface.
- Web up – the operator can, at the touch of a button on the touch screen operator interface, release the unwind brake to allow for easier webbing up of the machine.
Splicing Table
- 700mm (27.5″) inspection area prior to web guiding and slitting.
- Adjustable splicing facility.
- Pneumatic web clamps.
- Tape dispenser.
BST electronic web guide.
- Ultrasonic sensor – enables guiding of opaque and clear materials.
- Adjustable web guide sensor.
- +/- 25mm (1″) correction.
Draw Head
- Quick release pneumatically operated nip roller against a driven draw roller.
- The silicone nip roller does not allow labels to attach themselves to it, reducing downtime.
- Fully adjustable to allow for different label stocks.
- The draw roller is driven by a 1.5Kw (2 hp) motor.
Slitting
- 3 slitting knives
- Minimum slit width 13mm (0.51″)
- Lateral knife adjustment +/- 8mm (0.31″)
- Razor slitting with 3 razor knives
- Lateral knife adjustment of razor slitting
- Interlocked cutter guard
Rewind
- 1 Product rewind.
- Maximum rewind diameter: 360mm (14″).
- 76mm (3″) diameter with quick change air shaft
- Automatic taper tension control
- Servo driven rewind
- Labels in / labels out rewinding
- Note: Prepared to accept a second rewind and can be upgraded prior to sale.
Count Facility
- Labels
- Linear – metres & feet
- Total count
- Batch count
- Auto calculation of slow down and stop irrelevant of web speed.
- TLC – Total length count until reset by the operator.
Colour Touch Screen Operator Interface
- Highlights machine status, error messages and warnings
- Counting options
- Tension settings
- Job storage for easy & quick job set ups – 100 job capacity
Speed – 250 metres / minute – 820 feet / minute – dependent on material.
Year Of Manufacture: December 2014
Serial Number: 14120299
Daco DF350SRD Digital Converting and Finishing Press
The machine has never been used and is currently located at a client in the USA.
Web Width
- Maximum web width: 350mm (13.75″)
- Minimum web width: 200mm (8″)
Unwind
- Maximum unwind diameter: 600mm (23.6″).
- 76mm (3″) diameter air shaft.
- Merobel electromagnetic particle brake.
- End of roll function – The user can program the roll end diameter – slowdown and/or stop – The system does not use any roll followers or external sensors that can be damaged at roll changes. The diameter is programmed from the touch screen operator interface.
- Web up – the operator can, at the touch of a button on the touch screen operator interface, release the unwind brake to allow for easier webbing up of the machine.
BST Electronic Web guide
- Ultrasonic sensor – enables guiding of opaque and clear materials.
- Adjustable web guide sensor.
- +/- 25mm (1″) correction.
- Integral splice table with pneumatic interlocked web clamps.
- Tape dispenser for splicing
Servo Driven Semi-rotary Die Cutting Station
- Die-cut to register servo drive system – with an accuracy of 0.25mm (0.010″).
- 176T (22″) magnetic die cylinder for semi-rotary applications.
- Semi-rotary cutter repeat lengths: 50-457mm (2″-18″).
- Full rotary cutter repeat lengths: 203-558mm (8″-22″).
- Through hardened anvil – 120T – 15″ repeat.
- Precision ground 20mm (0.78″) thick die plates.
- Gearing – 1/8 cp, 20-degree pressure angle.
- Lateral die adjustment.
- Fully adjustable driven capstan roller.
- Matrix / Waste Rewind – 600mm (23.6″) diameter.
- 76mm (3″) mechanical mandrel for waste rewind.
Draw Head
- Pneumatically operated silicone nip roller against a driven draw roller.
- The silicone nip roller does not allow labels to attach themselves to it, reducing downtime.
- Fully adjustable via a regulator and gauge.
- On / off feature to allow for easy webbing up of the machine.
- Interlocked so that the machine can not be started with the nip roller off.
Slitting
- 3 rotary scissor slitting knives (shear knife).
- Minimum slit width: 13mm (0.51″).
- Lateral knife adjustment: +/- 8mm (0.31″).
- Removable interlocked cutter guard.
- Dual knife box configuration to allow razor slitting to be fitted.
Product Rewind
- 1 Product rewind
- Max rewind diameter: 600mm (23.6″).
- 76mm (3″) diameter air shaft.
- Servo driven.
- Automatic taper tension control.
Count Facility
- Labels
- Linear – metres & feet
Colour touch screen HMI operator interface
- Highlights machine status, error messages and warnings
- Counting options
- Tension settings
- Job storage allows for easy & quick job setups – 100 jobs
Maximum Web Speed
- Semi-rotary 80m/minute (262 feet/minute) – dependent on plate size
- Full rotary 175m/minute (575 feet/minute) – dependent on material
Modem connection for machine diagnostics & software upgrades
Run Hour Meter
Solid construction – built on a 3mm (0.118″) cabinet with a precision ground steel 16mm (0.62″) main plate.
Optional Equipment Fitted
RotoMetrics Hydra Jacks – die pressure gauges, quick release (per die station) – modified guarding
RotoMetrics MaxLyte 176T magnetic semi-rotary die cylinder
DBS-350ES back scorer – 2 knife holders (for edge trimming & winding with waste)
Foot pedal to jog machine (assists in webbing up the machine)
Bottom product rewind with 76mm (3”) air mandrel
Laminating station – laminate with a carrier – carrier rewind
Laminating silencer
Waste Lay-on roller
